AnimatedArmor

Living, glowing custom armor for your server — no client mods required.

AnimatedArmor turns your static Nexo or ItemsAdder custom armor into smooth, GPU-animated
gear that plays right on the player's body, for everyone around them. Frame-by-frame animation,
glowing emissive detail, and full shaderpack support — all driven automatically from the armor
textures you already make. If you can make a custom armor set, you can animate it.

ItemsAdder doesn't animate its component (equipment-tag) armor on its own — AnimatedArmor adds it.

☑ Works on Java and Bedrock

Runs on Java servers out of the box. For Bedrock players, the generated pack converts cleanly
with SMCConverter (Java → Bedrock)
— tested and working, so your animated armor reaches every player on a cross-play server.

Converter docs: docs.smcconverter.com

🙏 A massive thank you to SayMC, the creator of SMCConverter, for getting AnimatedArmor
working on Bedrock.

Platform	Paper 1.21.6 – 26.2 (recommended 1.21.11+), Java 21
Requires	Nexo or ItemsAdder 4.0.18+ to work (either one)
Optional	PacketEvents (prevents textures flashing on player).
Clients	Java: vanilla + shaderpack (Iris/OptiFine), auto-detected. Bedrock: via SMCConverter (Java → Bedrock)
Config per armor	None — reads your Nexo / ItemsAdder armor automatically

Contents

• Quick Start
• Installation
• Creating Animated Armor
• Nexo
• ItemsAdder
• Emissive / Glow
• Configuration
• Commands & Permissions
• How It Works
• Compatibility
• Troubleshooting
• FAQ

---

Quick Start

AnimatedArmor ships with a ready-made example set (Cherry) for both backends. With
AnimatedArmor installed alongside Nexo or ItemsAdder, run:

/aarmor generate cherry

/aarmor generate cherry installs the example into whichever backend is present. Then apply it and
equip a piece:

On Nexo

/nexo reload all
/nexo give <you> cherry_chestplate

On ItemsAdder

/iareload
/iazip
/iaget           (grab the pieces from the IA GUI)

It animates on your body, glows, and everyone around you sees it. Use it as a working reference for
building your own — see Creating Animated Armor.

---

Installation

| Requirement | Notes |
|—|–|
| Paper (or a Paper fork) | |
| Java 21 | The plugin is built for Java 21. |
| Nexo or ItemsAdder | One is required. AnimatedArmor hooks whichever is installed (it can run with both). It disables itself on startup only if neither is present. |
| PacketEvents | Optional but recommended. When present, AnimatedArmor rewrites in-flight equipment packets so viewers never see a flash of the raw texture strip. |

Steps

1. Stop the server.
2. Drop AnimatedArmor.jar into plugins/ (alongside Nexo and/or ItemsAdder, and PacketEvents if you use it).
3. Start the server. On first run it writes a default config.yml.
4. Set up an animated armor (see below) or run /aarmor generate cherry for the example.
5. Rebuild the pack — Nexo: /nexo pack (or /nexo reload all); ItemsAdder: /iareload then /iazip.

On enable you'll see the backend it hooked:

[AnimatedArmor] Hooked Nexo — armor with an animation .mcmeta will animate on the next Nexo pack generation.
[AnimatedArmor] Hooked ItemsAdder — component armor with an animation .mcmeta will animate on the next IA pack build (/iazip).
[AnimatedArmor] AnimatedArmor enabled.

After a pack build, a working set logs something like:

[AnimatedArmor] Animated entity/equipment/humanoid/cherry.png (24 frames, frametime 8, interpolated, emissive)
[AnimatedArmor] Patched entity.fsh in base to animate armor.
[AnimatedArmor] Shaderpack fallback: generated 192 per-frame equipment asset(s).

---

Creating Animated Armor

You don't register anything in AnimatedArmor's config — it reads your existing armor automatically.
Set the armor up in Nexo or ItemsAdder as normal, then make two small additions to the armor-layer
textures.

The animation itself is identical for both backends — a vertical frame strip plus an animation
.mcmeta. Only the file names/locations and the rebuild command differ. The shared rules:

1. Make the armor-layer texture a vertical frame strip. Stack the frames top to bottom in one
PNG. A single armor-layer frame is width × (width / 2), so a 64-wide layer is 64×32 per frame
and the strip height is 32 × frameCount:

Frames	Strip size (64-wide)
2	64 × 64
8	64 × 256
24	64 × 768

You need at least 2 frames.

2. Add an animation .mcmeta next to each strip, named after it (<strip>.png.mcmeta):

{
  "animation": {
    "frametime": 2,
    "interpolate": true
  }
}

• frametime — ticks per frame (20 ticks = 1 second). Omit it and default-frametime is used.
• interpolate — true blends smoothly between frames; false snaps.

3. Leave the control-pixel corner clear. AnimatedArmor stores timing data in the **top-left
3 pixels of frame 0** — keep that corner empty/transparent in your art.

4. Rebuild the pack (per backend, below). Rejoin (or re-accept the pack) and it animates on
anyone wearing it.

Tuning: speed-multiplier scales every animation; default-frametime sets the frametime used
when a .mcmeta omits it (see Configuration).

Nexo

Prerequisite: a working Nexo custom armor set (item + equippable → asset_id + the usual
_armor_layer_1 / _armor_layer_2 textures). If it shows up statically in-game, you're ready.

• Layer strips are Nexo's normal source textures, found by file name (in any folder):

(leggings). Add the matching <prefix>_armor_layer_1.png.mcmeta.

• Location: either the main pack (Nexo/pack/assets/…) or a Nexo external pack

(Nexo/pack/external_packs/<name>/…) — both are scanned.

• Rebuild: /nexo pack (or /nexo reload all).

ItemsAdder

ItemsAdder's component (equipment-tag) armor — the modern equipments: block with layer_1 /
layer_2 — is exactly what IA does not animate itself. AnimatedArmor adds the animation.

Prerequisite: a working IA component armor set. In your namespace config:

equipments:
  cherry:
    type: armor
    layer_1: armor/cherry/layer_1
    layer_2: armor/cherry/layer_2

• Layer strips live in ItemsAdder/contents/<namespace>/textures/armor/<name>/:

layer_1.png.mcmeta beside them.

• Rebuild: /iareload then /iazip.

The armor folder name must match the equipment name (IA's own convention — armor/cherry/ for
equipment cherry).

IA re-encodes equipment textures when it builds the pack, so AnimatedArmor reads your original
strips straight from ItemsAdder/contents/… — no quality loss, no manual steps.

Run /aarmor generate cherry on an IA server to drop in a complete, working example you can copy.

---

Emissive / Glow

AnimatedArmor can make parts of your armor glow full-bright, in step with the animation.
Optional, no client mods needed. Works the same on Nexo and ItemsAdder.

Drop an emissive strip next to the colour strip, same size, with an _e suffix:

Backend	Layer 1 emissive	Layer 2 emissive
Nexo	<prefix>_armor_layer_1_e.png	<prefix>_armor_layer_2_e.png
ItemsAdder	armor/<name>/layer_1_e.png	armor/<name>/layer_2_e.png

Rules:

• Non-black pixels glow; black/transparent pixels don't.
• The _e strip must be the same dimensions as its colour strip. If it isn't, the emissive is

ignored (with a warning).

• No .mcmeta needed on the _e strip — it follows the colour strip's timing.

Glow is delivered per client state: vanilla / Iris-no-shaderpack via the injected shader (baked into
the frame's alpha); shaderpack ON via labPBR _s (set your pack's RP Support to labPBR,
e.g. Complementary); OptiFine via its own _e.png convention.

---

Configuration

config.yml. You never list armors here — the plugin reads your Nexo / ItemsAdder armor
automatically.

# Scale every animation's playback speed. 1.0 = as the .mcmeta asks; 2.0 = twice as fast.
speed-multiplier: 1.0

# Frametime (ticks per frame) assumed when a strip's .mcmeta omits it. Minecraft's default is 1.
default-frametime: 1

# Log each armor texture animated during pack generation.
debug: true

# Core shader patching (advanced)
shader:
  skip-overlays:
    - mythicarmor

# Shaderpack fallback (advanced)
shader-fallback:
  enabled: true

Key	Default	What it does
speed-multiplier	1.0	Global playback-speed scale for all animations.
default-frametime	1	Frametime used when an armor's .mcmeta omits one.
debug	true	Logs each armor texture animated during pack generation.
shader.skip-overlays	[mythicarmor]	Resource-pack overlay directory names (case-insensitive substring) whose core entity.fsh must not be patched — used to avoid breaking 3D-armor plugins that ship their own entity shader (MythicArmors).
shader-fallback.enabled	true	Generates one equipment asset per frame so shaderpack players (whose GPU can't run the core-shader animation) still see the armor animate via per-tick frame swapping.

After changing the config, apply it with /aashader reload (or restart / rebuild the pack).

---

Commands & Permissions

Command	Description
/aarmor generate cherry	Installs the bundled Cherry example into whichever backend is present — Nexo (external_packs/ + items/, then /nexo reload all) and/or ItemsAdder (contents/animated_armor/, then /iareload + /iazip).
`/aashader [on\	off\	auto\	status]`	Per-player animation mode. on = shaderpack frame-swap, off = smooth GPU, auto = client-brand detection (default), status = show your mode. Saved across relogs.
/aashader reload	Reload config.yml (admin).
/aashader debug <player>	Diagnostic report for a player (admin).

Both backends auto-detect shaderpack players and frame-swap them. The per-player /aashader
override is available on the Nexo path; the ItemsAdder path uses automatic detection.

Permission	Default	Grants
animatedarmor.shader	everyone	`/aashader on\	off\	auto\	status`
animatedarmor.admin	op	/aashader reload, /aashader debug, /aarmor generate

---

How It Works

At pack build, AnimatedArmor hooks the pack-generation step of whichever backend is running
(Nexo's post-generate event, or ItemsAdder's pack-compressed event) and:

1. Finds animated armor — Nexo: scans Nexo/pack/assets/ and Nexo/pack/external_packs/

for *_armor_layer_1/2.png.mcmeta. ItemsAdder: reads the original strips + .mcmeta from
ItemsAdder/contents/<ns>/textures/armor/<name>/ (the backend drops the .mcmeta when it builds
the equipment texture, so the timing is recovered from the source).

1. Bakes the animation — packs the frame count, frametime and interpolation flag into control

pixels in frame 0, and merges the emissive _e strip if present.

1. Wires up the shader — merges its animation branch into every core entity.fsh in the pack

(base + version overlays) rather than clobbering yours; ships its own only if nothing overrides it.

1. Generates fallback frames (if shader-fallback.enabled) for the frame-swap path — smoothly

interpolated where the .mcmeta asks for it.

Two render paths, chosen per player:

• GPU core-shader (vanilla players) — the shader reads the control pixels and the world time and

samples the current frame every render. No per-tick server work.

• Frame-swap fallback (shaderpack players, and Bedrock via Geyser) — shaderpacks replace core

shaders, so for those players AnimatedArmor swaps the worn armor's frame server-side each tick via
client-only equipment packets. Because each frame is a normal texture, any shaderpack renders it.

Who gets which is auto-detected by client brand and can be overridden with /aashader. With
PacketEvents installed, AnimatedArmor also rewrites outgoing equipment packets so shader viewers
never flash the raw strip when armor changes.

---

Compatibility

• Nexo and ItemsAdder — either one works; AnimatedArmor hooks whichever is installed and can

run with both.

• PacketEvents — optional; removes the one-frame raw-strip flash on equip.
• Other entity-shader plugins (Animotions, ItemsAdder's own emote shader, …) — compatible:

AnimatedArmor merges into the existing core entity.fsh instead of replacing it.

• 3D-armor plugins (MythicArmors) that ship their own core entity shader — AnimatedArmor leaves

their shader alone (via shader.skip-overlays) so it doesn't break their 3D armor.

• Clients — vanilla and shaderpack (Iris/OptiFine) are both supported and auto-detected; players

can toggle with /aashader.

• Bedrock (cross-play) — Bedrock clients (via Geyser) don't run Java resource packs directly,

but the generated pack converts cleanly for Bedrock with
SMCConverter (Java → Bedrock),
which AnimatedArmor has been tested with. Converter setup docs:
docs.smcconverter.com.

• Minecraft — supported 1.21.6 – 26.2 (1.21.5 and below are not supported — those clients

use an older core entity shader). Recommended/tested 1.21.11 – 26.2, Java 21. ItemsAdder
tested on 4.0.18.

Note: AnimatedArmor's GPU animation rides the vanilla core entity shader, which Mojang can
restructure between Minecraft versions. If a future update ever changes it, the console will say so
at pack generation (see Troubleshooting), and shaderpack players are unaffected (they use the
frame-swap fallback).

---

Troubleshooting

AnimatedArmor is loud — most problems print a clear reason at pack build. Keep debug: true.

Message	Meaning	Fix
No animated armor found — no *_armor_layer_1/2.png.mcmeta ... (Nexo)	No animation .mcmeta was found in pack/assets/ or pack/external_packs/.	Add a .mcmeta next to each armor-layer strip; make sure the textures are in the main pack or an external pack.
No animated ItemsAdder armor found — no ... armor/<name>/layer_N.png.mcmeta ...	No animation .mcmeta beside the IA source strips.	Add layer_1.png.mcmeta (and/or layer_2) in contents/<ns>/textures/armor/<name>/; ensure the folder name matches the equipment name.
Skipped <tex> — … neither the colour strip nor its _e has 2+ frames	The strip isn't a multi-frame strip.	Make it a vertical strip of 2+ frames, each width × (width/2).
Emissive for <tex> was ignored — the _e strip must match the colour strip's width.	The _e strip's size doesn't match.	Make the _e strip the same dimensions as its colour strip.
Found N ... .mcmeta ... but no matching entity/equipment texture	The .mcmeta prefix doesn't line up with a generated equipment texture.	Nexo: check the strip prefix matches the armor + the item's asset_id. ItemsAdder: the armor folder name must match the equipment name.
Left overlay/<dir> entity.fsh alone (third-party 3D-armor shader …)	An overlay matched shader.skip-overlays and was skipped on purpose (e.g. MythicArmors).	Intended. Remove it from shader.skip-overlays only if it isn't a 3D-armor shader.
Could not patch <where> entity.fsh — unrecognised structure	The core shader structure wasn't recognised (usually after a Minecraft update).	Report the MC version; the shader needs an update. Frame-swap still animates shaderpack players meanwhile.

Armor shows as a static strip — the animation didn't wire up for that viewer, or the client is
still on the old cached pack. First relog / re-accept the pack after any rebuild (the pack hash
changes). Then check the pack-build logs; common causes: the strip isn't multi-frame, the
control-pixel corner was painted over, or the player is on a shaderpack with
shader-fallback.enabled: false.

It animates for some players but not others — that's the vanilla-vs-shaderpack split. Have the
player run /aashader status, and /aashader on|off to force it (Nexo path).

A flash of the raw strip on equip — install PacketEvents.

---

FAQ

Do I list each armor in the config? No — AnimatedArmor reads your Nexo / ItemsAdder armor
automatically.

Does it work with ItemsAdder? Yes. It animates IA's component (equipment-tag) armor, which IA
doesn't animate on its own — GPU animation for vanilla clients, frame-swap for shaderpack/OptiFine/
Bedrock. Install with /aarmor generate cherry, then /iareload + /iazip.

Do players need a client mod? No. Vanilla players get the GPU animation; shaderpack players get
the automatic frame-swap fallback.

Does it work under shaderpacks (Iris/OptiFine)? Yes, via the frame-swap fallback.

How many frames? At least 2. Each frame is width × (width/2), stacked vertically.

Does it modify the real armor item? No — the frame-swap is a client-only visual change per
viewer; the real item is never touched.

What's the performance cost? The GPU path is essentially free server-side. The frame-swap does
lightweight per-tick packets, and only for shaderpack players. Main cost is pack size (one asset per
frame for the fallback).

Can I animate leggings? Yes — use the layer-2 strip (_armor_layer_2 on Nexo, layer_2 on
ItemsAdder) + its .mcmeta.

Can armor glow? Yes — add a matching _e strip. See Emissive / Glow.

Where can the textures live? Nexo: main pack (pack/assets/) or a Nexo external pack
(pack/external_packs/) — both are scanned. ItemsAdder: your namespace's
contents/<ns>/textures/armor/<name>/.

How do I change animation speed? speed-multiplier in the config, or each armor's frametime.

Does it work on Bedrock? Yes — convert the generated pack for Bedrock clients with
SMCConverter (Java → Bedrock)
(setup guide: docs.smcconverter.com), which AnimatedArmor has been
tested with. Great for cross-play servers.
